Mechanical Engineering Equipment Gallery


External usage enquiries (research_equipment*oist.jp) (replace* by @)

Engineering Section (mechanical*oist.jp) (replace* by @)

CNC Machining Center

Maker: Mazak

Model: j-600/5X

Features: 5-axis CNC machining; Max. workpiece: Ø730 mm x H450 mm

CNC Machining Center

Maker: Hurco

Model: VM5i

Features: 3-axis CNC machining

CNC Lathe

Maker: Hurco

Model: TMX10MYi

Features: Max. turning diameter/length: 375/670 mm

Wire-EDM

Maker: Sodick

Model: AL400G

Features: Max. workpiece (W x D x H): 600 x 470 x 230 mm

Die Sinker-EDM

Maker: Chmer

Model: CM323C

Features: Work tank size (W x D x H): 820 x 500 x 300 mm

Precision Grinding Machine

Maker: Okamoto

Model: PFG450DXC

Features: Precision grinding

Users Corner

Maker: Multiple

Model: Multiple

Features: Bandsaw; Drill press; Milling machine; Lathe

3-D Printer

Maker: Stratasys

Model: Objet 500 Connex 3

Features: Multiple materials and colours; Resolution XY-axis 600 dpi, Z-axis 1600 dpi; Build size (W x D x H): 490 x 390 x 200 mm

3-D Printer

Maker: Ultimaker

Model: Ultimaker S5

Features: Multiple materials and colours; ; Build size (W x D x H): 330 x 240 x 300 mm

Vacuum Oven

Maker: Eyela

Model: VOS-601SD

Features: Temperature range 40-200ºC; Chamber size (W x D x H): 600 x 600 x 600 mm

Coordinate Measuring Machine

Maker: Zeiss

Model: O-Inspect 322

Features: Accuracy 2.9 + L/150 µm; Measurement range (W x D x H): 300 x 200 x 200 mm

Helium Leak Detector

Maker: Agilent

Model: VSPR02

Features: Highly portable, easy operation

Helium Leak Detector

Maker: Pfeiffer Vacuum

Model: ASM 340

Features: Highly portable, easy operation

Laser engraver/cutter

Maker: Universal Laser Systems

Model: VLS4.75

Features: Working area (X x Y x Z): 610 x 475 x 216 mm; 75 W CO2 laser, Engraving and cutting of various materials
