FY2012 Annual Report

Information Processing Biology Unit

Unit: Information Processing Biology Unit
Principal Investigator: Ichiro Maruyama
Research Theme: Information Processing by Life



Abstract

Our unit is interested in understanding how neurons/cells detect extracellular information and transmit it into the cell. For the last 25 years, ligand-induced dimerization has been widely thought to be a common property of transmembrane signaling mechanisms for all known growth factor and cytokine receptors, among others. In previous years, however, we have found that growth factor receptors such as epidermal growth factor (EGF/ErbB) receptors and nerve growth factor (NGF) receptor have preformed, inactive, dimeric structures prior to ligand binding. We have proposed an alternative ‘rotation/twist’ model in that ligand binding to the extracellular domains induces a rotation or twist of the transmembrane domains parallel to the plane of the membrane. This activates the intracellular domains, which often encode or physically interact with enzymes such as kinases, by rearranging their dimeric structures. This fiscal year, we have also shown that a transmembrane receptor-type guanylyl cyclase, GCY-14, in the ASEL sensory neuron of the nematode Caenorhabditis elegans (C. elegans), also exists as a homodimer before its activation by extracellular alkaline pH.

We are also interested in understanding how cellular networks in the nervous system processes environmental information to regulate animal behaviors, including learning and memory. In order to survive, animals must closely monitor environmental and body fluid pH. However, little is known about how animals monitor alkaline pH in the environment at molecular and cellular levels. In this study, we have employed C. elegans as a model system. While C. elegans is attracted to mildly alkaline pH, it is repelled by strongly alkaline pH. In this fiscal year, we have demonstrated that multimodal sensory neurons (ASH) sense strong environmental alkalinity through activation of transient receptor potential vanilloid type (TRPV) ion channels encoded by the osm-9 and ocr-2 genes.

In recent years, we have also tried to develop protocols to study learning and memory in C. elegans, and have found that the animal can learn and form associative long-term memory. It can learn to associate an appetitive or aversive olfactory stimulus with an unconditioned stimulus, and can retain the associative long-term memory. This fiscal year, we are continuing to elucidate neural networks responsible for the associative long-term memory.

These results provide insights into the molecular mechanism underlying information transfer from the outside of neurons/cells to the inside, as well as an understanding of neuronal networks that control animal behaviors in response to external stimuli. These findings may also be invaluable in developing pharmaceuticals for human diseases such as cancers and mental diseases.

1. Staff

  • Cahyo Budiman (joint appointment with Skoglund unit)
  • Bunsho Itoh
  • Yoko Kudeken (until June, 2012)
  • Hiraku Miyagi
  • Takeshi Mise
  • Takashi Murayama
  • Hideki Muto (from May, 2013)
  • Hitomi Ohtaki (from March, 2013)
  • Toshio Sassa
  • Miyako Tsuchiya (from June, 2012 to March, 2013)

2. Collaborations

  • Theme: Functional analyses of small G protein and their downstream proteins
    • Type of collaboration: Joint research
    • Researchers:
      • Ken-ichi Kariya, University of the Ryukyus
      • Tsuyoshi Asato, University of the Ryukyus
      • Kimiko Nonaka, University of the Ryukyus
  • Theme: Optical analysis of epidermal growth factor receptor
    • Type of collaboration: Collaborative research
    • Researchers:
      • Thorsten Wohland, National University of Singapore

3. Activities and Findings

3.1. Project Aims

All forms of life are separated from their environments by cell membranes, and all neurons/cells have cell-surface receptor proteins that span the membranes in order to transmit external information, such as environmental changes and cell-cell communications, into the cell. Such information flow is fundamental for all organisms, from bacteria to humans. Dysregulation of cell surface receptor molecules causes a variety of impairments, including mental and developmental diseases and cancers in humans. (1) We wish to understand at the molecular level how external information is sensed and transmitted into the inside of neurons/cells by cell-surface receptors. We also seek to know how the information is processed, how it is transferred to other parts of the cells, and how it regulates other cellular activities. (2) We wish also to understand higher level information processing through cellular networks. Specifically, we want to know how external information is sensed and transmitted through sensory neurons, how it is processed by the nervous system, and how it controls animal behaviors, including learning and memory.

3.2. Progress Report

3.2.1. Information processing by neurons/cells

3.2.1.1. Background.

The bacterial cell-surface receptor, Tar, recognizes aspartate molecules in the environment, and directs bacterial cells toward higher concentrations of the attractant as a nutrient, or toward lower concentration of repellents, such as nickel and cobalt ions. This transmembrane signaling is mediated by Tar in its homodimeric form on the cell surface. We have previously shown that Tar activity is regulated by its ligands, which bind to the extracellular domain of the receptor and lock/freeze the rotational/twist movement of the receptor’s transmembrane domains (Maruyama et al., 1995). This locking/freezing of the rotation/twist at one position by the attractant is likely to inhibit the associated histidine kinase Che A, while the locking/freezing at another position by the repellent seems to activate the kinase activity (the rotation/twist model).

We also analyzed the molecular mechanism underlying activation of the human epidermal growth factor receptor (EGFR) family of cell-surface receptor tyrosine kinases, also known as ErbB or HER. EGF/ErbB receptors play a pivotal role in the development of organisms, and are frequently implicated in human cancers. Furthermore, these receptors also regulate neural activities, and mutations of these receptor genes are frequently associated with mental diseases. The receptor family consists of four members, EGFR/ErbB1, ErbB2/Neu/HER2, ErbB3/HER3 and ErbB4/HER4, and has a large (~620 amino acid ) extracellular ligand-binding region, a single, transmembrane alpha-helix, and an intracellular region containing the tyrosine kinase and its regulatory domain. They form a network of homo- and heterodimers. ErbB2 can only be regulated indirectly, and is thought to be the preferred heterodimerization partner for other ErbB receptors. ErbB3, on the other hand, must associate with an ErbB family member that has an active tyrosine kinase in order to respond to its own ligand, neuregulin (NRG).

Ligand-induced dimerization has widely been thought to be a property common to the transmembrane signaling mechanism of all known growth factor receptors including the EGF/ErbB receptors (Dimerization Model). According to the model, receptor dimerization is responsible for autophosphorylation of the intrinsic kinase activity, which is mediated by an intermolecular process. The model holds that ligand binds to the monomeric form of the receptor, inducing its dimerization and resulting activation. However, it remains controversial whether the receptor actually has a monomeric or dimeric structure prior to ligand binding

Using chemical cross-linking and sucrose density-gradient centrifugation, we recently discovered that in the absence of bound ligand, EGFR has the ability to form a dimer and that the majority (>80%) of receptors exist as preformed dimers on the cell surface. We also analyzed receptor dimerization by inserting cysteine residues at strategic positions along the longitudinal axis of the alpha-helical extracellular juxtamembrane region. Mutant receptors spontaneously formed disulfide bridges and transformed NIH3T3 cells in the absence of ligand, depending upon the positions of the cysteine residues inserted. Kinetic analysis of disulfide bonding indicates that ligand binding induces flexible rotation or twist of the juxtamembrane region of the receptor in a plane parallel with the lipid bilayer. The binding of an ATP competitor to the intracellular kinase domain also induced similar flexible rotation/twist of the juxtamembrane region. All disulfide-bonded dimers had flexible ligand-binding domains with the same biphasic affinities for ligand as the wild type. Based on these results, we have proposed an alternative ‘rotation/twist’ model for the molecular mechanism of EGF receptor activation, in which ligand binding to the flexible extracellular domains of the receptor dimer induces rotation/twist of the juxtamembrane regions, hence the transmembrane domains, rearrange the kinase domains for the receptor activation. Indeed, this rotation/twist model (Fig. 1.; Moriki et al., 2001; Tao and Maruyama, 2008) is consistent with recent results by others in which the receptor kinase, transmembrane and unactivated extracellular domains are shown to have homodimeric structures.



Fig. 1. ‘Rotation/twist’ model for the molecular mechanism of EGFR activation by ligand binding. Adapted from Tao & Maruyama (2008) JCS, 121, 3207.

To support the ‘rotation/twist’ model, we have recently determined preformed, homo- and heterodimeric structures of EGFR and ErbB2 at physiological expression levels (~104 molecules per cell), using fluorescence microscopy, fluorescence resonance energy transfer (FRET) and fluorescence cross-correlation spectroscopy (FCCS) (Liu et al., 2007). When fluorescent protein (FP)-fused EGFR and ErbB2 were expressed on the cell surface of Chinese hamster ovary cells at physiological expression levels, FRET was detected between the donor and acceptor FPs in the absence of ligand. Furthermore, cross-correlation between FPs separately fused to EGFR or ErbB2 was also observed by FCCS, indicating that EGFR and ErbB2 molecules diffuse together as homo- or heterodimers in the cell membrane. These results demonstrate that prior to ligand binding, the cell-surface receptors can spontaneously form homo- and heterodimers, irrespective of their expression levels ranging from ~2 x 104 to ~5 x 106 molecules per cell.

Furthermore, we have been analyzing preformed homo- and heterodimeric structures between all the members, EGFR, ErbB2, ErbB3, and ErbB4, of the receptor family by employing bimolecular fluorescence complementation (BiFC) assay. We have found that all members display preformed, yet inactive, homo- and heterodimeric structures in the absence of bound ligand (Tao & Maruyama, 2008). Ligand-independent dimerization of EGF/ErbB receptors occurs in the endoplasmic reticulum (ER) before newly synthesized receptor molecules reach the cell surface. Furthermore, we have also found that ErbB3 was localized in the nucleus when expressed alone or together with ErbB4. When coexpressed with EGFR or ErbB2, however, ErbB3 was located in the plasma membrane. These results indicate that all the EGF/ErbB receptors exist as homo- and heterodimers before ligand binding, consistent with the ‘rotation/twist’ model. ErbB receptors exist as dimers on the cell surface, mainly through interaction between their transmembrane domains, intracellular kinase domains and C-terminal tails. Receptor dimers have flexible extracellular domains, and perhaps can take two major conformations, closed and open states. Ligand binding to the open form of the receptor dimer stabilizes the extracellular domains, resulting in approximately 140° rotation or twist of the transmembrane domains about its helix axis parallel to the plane of the cell membrane, dissociate the symmetric back-to-back kinase domains, and then rearrange the kinase domains to take head-to-tail asymmetric configuration for the receptor activation.

As described above, different cell-surface receptors, bacterial Tar and human EGF/ErbB receptors, seem to be similarly regulated by their ligands in order to transmit the extracellular information to the inside of the cell. Ligand binding regulates the rotation/twist of the receptor’s transmembrane domain parallel to the plane of the plasma membrane. Therefore, we have been continuing to test the “rotation/twist” model for the molecular activation mechanism of other cell-surface receptors, including Tar, EGF/ErbB receptors and neurotrophin receptors. Indeed, we have recently elucidated that the neurotrophin receptor TrkA is present as a preformed, yet inactive, dimer in living cells (Shen & Maruyama, 2011). We have also previously found that the intracellular domain of the EGF/ErbB receptors plays a crucial role in the spontaneous formation of receptor dimers (Tao & Maruyama, 2008). Thus, an increasing number of studies demonstrate that many transmembrane receptors, which include receptors previously thought to be activated by ligand-induced receptor dimerization, exist as preformed, yet inactive, homo- and heterodimers in living cells. These receptors include the aspartate receptor Tar, EGF/ErbB receptor family members, erythropoietin receptor (EpoR), growth hormone receptor (GHR), Toll-like receptor-9 (TLR9), natriuretic peptide receptor A (NPRA), nerve growth factor (NGF) receptor TrkA, and brain-derived neurotrophic factor (BDNF) receptor TrkB. In the cases of Tar, EGFR, GHR, and NPRA, it has been proposed that ligand binding induces or stabilizes the rotation/twist of transmembrane domains of preformed receptor dimers for the rearrangement of intracellular domains necessary for activation.

3.2.1.2. Crystal structure of Tar with a repellent.

Three-dimensional (3D) structures of the extracellular ligand-binding domain of the bacterial aspartate receptor Tar, with and without bound aspartate were determined 20 years ago, and others have reported that the transmembrane domain shifts vertically 1-2 Å when aspartate binds. This suggests that the receptor structures without and with bound aspartate are very similar, consistent with our ‘rotation/twist’ model for the mechanism of Tar activity regulation by aspartate (Maruyama et al., 1995). Furthermore, the ‘rotation/twist’ model predicts that another cofactor for Tar, nickel, a repellent in E. coli chemotaxis, stabilizes the transmembrane domains in a distinct rotational orientation. That is, nickel induced rotation/twist of the transmembrane domains parallel with the plane of the cytoplasmic membrane. To test this model, this fiscal year we successfully crystallized the domain in the presence and absence of NiSO4. The 3D structures determined were very similar. Currently we are trying to examine whether the crystals contain Ni2+ ions.

3.2.1.3. EGFR domains required for the spontaneous dimerization in the absence of bound ligand.

Three-dimensional structures of the intracellular domain of EGFR recently determined by others suggest that the intracellular domain may function in spontaneous dimer formation. Through analyses of deletion mutants, indeed, we have found that the intracellular domain of EGFR enables dimerization in the absence of ligand. We are currently trying to identify domains and amino-acid residues required for dimerization by constructing point and deletion mutant receptors. We are particularly focusing on the intracellular domain of EGFR in which a stretch of negatively charged amino acid residues of the C-terminal tail seems to stabilize back-to-back kinase homodimers. In this fiscal year, we have confirmed that deletion of the C-terminal region encompassing negatively charged residues causes spontaneous activation of EGFR in the absence of bound ligand. This indicates that ionic interaction of negatively charged residues plays an essential role in stabilizing the homodimeric structure of EGFR, presumably by interacting with positively charged residues of the kinase domain.

Fig. 2. Three-dimensional structure of the EGFR kinase homodimer (A) and sequence alignment of negatively charged amino acid residues at the C-terminal tail of the EGFR family (B).

3.2.2. Information processing by the nervous system

3.2.2.1. Alkalinity sensation in C. elegans.

3.2.2.1.1. Background.

Like other animals, C. elegans detects various environmental cues, such as tastes and odors, mainly through its amphid sensilla. The amphids are the largest chemosensory organs, and each amphid includes 12 sensory neurons (ADF, ADL, AFD, ASE, ASG, ASH, ASI, ASJ, ASK, AWA, AWB, and AWC) with ciliated dendrites, as well as one sheath and one socket cell. Apart from AFD, the sensory dendrites of 11 neurons penetrate the sheath-cell ending, and the cilia of eight of these neurons, except those of AWA, AWB, and AWC, extend into the doughnut-like pore created by the socket cell where they are directly exposed to the external medium. These amphid neurons have roles in chemotaxis, thermotaxis, mechanosensation, osmotaxis, and dauer pheromone sensation.

Animals can survive only in a narrow pH range, and continuously monitor the pH of environment and body fluids. However, little is known about how animals monitor alkaline pH in the environment. Environmental mild alkalinity is one of attractive cues for C. elegans. From pH 2.8 - 10.4, wild-type animals prefer higher alkaline pH ranges, but they avoid pH ≥11.0 and ≤4.0. However, neurons and cell-surface molecules that sense low and high alkalinity have not been elucidated in C. elegans. Neural networks responsible for this worm’s attraction to mild alkalinity and aversion to strong alkalinity can also be efficiently analyzed, since wiring diagrams of all neurons have been reconstructed from electron micrographs of serial thin sections of whole C. elegans

3.2.2.1.2. Mild-alkalinity sensation.

Previously, we devised an agar plate assay with a linear pH gradient in order to investigate cellular and molecular bases for C. elegans’ chemotaxis toward low-alkaline pH. Along the pH gradient from pH 6.8-8.5, wild-type animals were attracted to higher pH regions, whereas che-1 mutants defective in chemosensory ASE neurons were not. To search for a molecular sensor for the low-alkaline pH, we performed a series of RNAi knock down experiments of genes encoding various channels, cell-surface receptors, and guanylyl cyclases, in conjunction with analysis of chemotaxis mutants previously known. Among the genes analyzed, tax-2, tax-4 and gcy-14 were found to be involved in C. elegans chemoattraction to low-alkaline pH. By imaging Ca2+ concentration changes using a Ca2+-sensing fluorescent protein, we also found that ASE-left (ASEL) is activated by a pH up-shift. GFP-tagged GCY-14, a transmembrane receptor-type guanylyl cyclase (RGC), was localized to ASEL sensory cilia, and in the gcy-14 mutant, ASEL did not respond to a pH up-shift. While wild-type ASI sensory neurons do not respond to pH up-shift, ASI neurons ectopically expressing GCY-14 were activated by a pH up-shift from pH 7.0-10.0. This suggests that GCY-14 is sufficient for alkaline pH sensation. These results indicate that GCY-14 acts as an alkaline pH sensor, and an increased concentration of cGMP opens the cGMP-gated cation channel TAX-2/TAX-4 for activation of ASEL. We have further dissected the GCY-14 molecule in order to determine which part of it recognizes environmental alkaline pH. GCY-14 consists of an extracellular domain, a membrane-spanning alpha-helix, and intracellular kinase-homology, and guanylyl cyclase domains. We swapped these domains one by one with those of other alkaline pH-insensitive RGCs, DAF-11 and ODR-1, to identify a domain that detects the low-alkaline pH. Results of this experiment demonstrate that the extracellular domain is responsible for the sensation. Furthermore, the results also indicate that GCY-14 acts as a homodimer on the cell surface of ASEL cilia. In this fiscal year, we have also tried to identify a histidine residue(s) in the extracellular domain that may play an essential role in alkaline-pH sensation. As shown in Fig. 3A, a mutated GCY-14 protein that substitutes Gln for His-174, was defective in rescue experiments of gcy-14 mutants, indicating that His-174 plays a critical role in alkaline pH sensation. Furthermore, when GCY-14 was ectopically expressed in alkaline pH-insensitive ASG chemosensory neurons, ASG was activated by pH up-shift from 6.8 - 10.0 (Fig. 3B). This indicates that GCY-14 is a sensor molecule for mildly alkaline pH. These results together with other data collected in the past years have been published (Murayama et al., 2013).





 Fig. 3. Ca2+ imaging of sensory neurons in wild-type and mutant C. elegans. (A) Intracellular Ca2+ transients in the alkalinity-sensitive ASEL chemosensory neuron in C. elegans. Traces in red, blue and yellow represent Ca2+ transients in the ASEL of gcy-14 animals, gcy-14 expressing wild-type GCY-14, and gcy-14 expressing GCY-14(H174Q), respectively. The black trace represents Ca2+ transients in wild-type ASEL. Timing of pH or NaCl concentration changes is represented by rectangular waves. (B) Ca2+ transients in alkaline pH-insensitive ASG neurons ectopically expressing GCY-14 in response to a pH up-step at t = 30 s. Wild-type animals with (blue) or without (red) the expression of GCY-14 in ASG.

3.2.2.1.3. Strong-alkalinity sensation.

During the work on mild alkalinity sensation described above, we found that C. elegans avoids higher pH than ~10.5 as a noxious stimulus in chemotaxis assays using agar plates divided into four quadrants. Using the plate assay, in previous years, we identified several genes that play pivotal roles in the avoidance behaviour: che-2, dyf-3, osm-1, and osm-5, which are required for chemosensation, and osm-9 and ocr-2, which encode subunits of type-V transient-receptor potential (TRPV) channels. Rescue experiments that employed dyf-3 and osm-9 mutants by injecting the respective cDNA into ASH chemosensory neurons indicate that ASH is a major neuron responsible for high alkaline pH sensation in C. elegans. This was confirmed by Ca2+ imaging in which a Ca2+ concentration increase was observed in ASH following stimulation with high alkaline pH. This fiscal year, we further confirmed that ASH sensory neurons are responsible for nociception of strongly alkaline pH using genetic rescue experiments and laser microsurgery of the neurons. These results have been published (Fig. 4; Sassa et al, 2013).



Fig. 4. Behavioral and cellular responses to strongly alkaline pH. (A) Avoidance responses of wild-type C. elegans to various alkaline pHs. (B) Behavioral analysis of wild-type animals with laser ablation of ASH, ADL, or ASI sensory neurons. (C) Ca2+ imaging of wild-type ASH neurons upon stimulation with various alkaline pHs. (D) Ca2+ imaging of ASH neurons of wild-type animals and mutants upon stimulation with pH 11.2. These figures are adapted from Sassa et al. (2013) in Neuroscience Letters (in press).

3.2.2.2. Associative learning and memory in C. elegans

3.2.2.2.1. Background.

C. elegans is an excellent model organism for the study of learning and memory. The hermaphrodite nervous system consists of only 302 neurons, and neural circuits, chemical synapses, and electrical gap junctions of these invariant neurons have completely been reconstructed from serial thin sections of electron micrographs. The worm body is transparent throughout its life so that neural activities can directly be observed using Ca2+-sensitive and/or voltage-sensitive fluorescent proteins in living animals.

Associative learning in C. elegans was first suggested from the finding that worms return to their temperature of cultivation if they had food at that temperature. Most of learning paradigms in C. elegans are based on pairing chemical cues or cultivation temperature with food or starvation. Rather than pairing chemical cues with food or starvation, however, it would be preferable for subsequent analysis of neural circuits responsible for associative learning and memory to use two defined chemical cues for conditioning of animals in associative learning paradigms.

3.2.2.2.2. Appetitive olfactory learning and associative long-term memory

In previous years, we developed an associative learning paradigm in C. elegans by classical (Pavlovian) conditioning of the animals with nonanol, as a conditioned stimulus (CS), and potassium chloride (KCl) as an unconditioned stimulus (US). Before conditioning, animals avoided nonanol, an aversive olfactory stimulus, and were attracted by KCl, an appetitive gustatory stimulus, in chemotaxis assays. In contrast, after eight-cycle massed (without intertrial intervals, ITI) or spaced (with 10-min ITI) training, animals were attracted to nonanol. Memory induced by the massed training was extinguished within three hours, while the spaced training induced memory that was retained for more than 12 hours. Animals treated with cycloheximide or actinomycin D failed to form long-lasting memory by the spaced training, whereas memory induced by the massed training was not significantly affected. These results indicated that the memory formation by the spaced training, but not by the massed training, required protein synthesis and mRNA transcription. Therefore, the memories induced by the massed and spaced training are classified as short-term/middle-term (STM/MTM) and long-term (LTM) memories, respectively. In support of this, C. elegans mutants defective in nmr-1, encoding an NMDA receptor subunit, failed to form both STM/MTM and LTM, while mutations in crh-1 encoding the CREB transcription factor affected only formation of LTM. Last fiscal year, we determined sensory neurons that detect nonanol in C. elegans as a step toward elucidating the neural networks responsible for associative learning and memory with nonanol and KCl. Olfactory avoidance assays of animals whose amphid AWB or ASH neurons were separately ablated by laser microsurgery, demonstrate that AWB is responsible for the perception of a low concentration, 0.1%, of nonanol. This fiscal year, we have been trying to identify neurons required for learning and memory using rescue experiments of the mutants.

3.2.2.2.3. Aversive olfactory learning and associative long-term memory

We have also been developing protocols for classical conditioning of C. elegans with propanol, as a CS and hydrochloride (HCl), pH 4.0, as a US. Before conditioning, worms were attracted to propanol, and avoided HCl in chemotaxis assays. However, after spaced or massed training, animals were either not attracted at all or were repelled by propanol on the assay plate. The memory after the spaced training was retained for 24 h, while the memory after the massed training did not even persist for 3 h. Animals pretreated with transcription and translation inhibitors failed to form the memory by spaced training, whereas the memory after massed training was not significantly affected by inhibitors and was sensitive to cold-shock anesthesia. Furthermore, memory after spaced training was reasonably disrupted by extinction learning, in which the worm is repeatedly exposed to the CS in the absence of US. Therefore, memories after spaced and massed training can be classified as LTM and STM/MTM, respectively. Consistently, like other organisms including Aplysia, Drosophila, and mice, C. elegans mutants defective in nmr-1, encoding an NMDA receptor subunit, failed to form both LTM and STM/MTM, while mutations in crh-1 encoding the CREB transcription factor affected only LTM. This work has recently been published (Amano & Maruyama, 2011). In this fiscal year, we have been trying to identify neurons required for learning and memory using rescue experiments of the mutants.

4. Publications

4.1 Journals

  1. Budiman, C., Furusho, H., Mishima, Y., Öfverstedt, L.-G., Skoglund, U. & Maruyama,  I. (2013) 65a  In Situ Visualization of Mouse Skeletal Muscle Ryanodine Receptor by Cryo-Electron Tomography. Biophysical Journal.

4.2 Oral and Poster Presentations

  1. Shen, J. and I. Maruyama: Brain-derived neurotrophic factor receptor TrkB exists as a preformed dimer in living cells. Experimental Biology 2012. San Diego Convention Center, San Diego, California, USA (April 21-25).
  2. Murayama, T., et al.: Alkaline pH sensation mediated by GCY-14, a transmembrane guanylyl cyclase. EMBO Conference Series C. elegans Neurobiology. EMBL Advanced Training Centre, European Molecular Biology Laboratory, Heidelberg, Germany (June 14-17, 2012).
  3. Itoh, B., et al.: Aversive olfactory learning and associative long-term memory in C. elegans. EMBO Conference Series C. elegans Neurobiology. EMBL Advanced Training Centre, European Molecular Biology Laboratory, Heidelberg, Germany (June 14-17, 2012).
  4. Sassa, T. and I. Maruyama: Neuropeptide signaling plays a vital role in high alkaline-pH avoidance in C. elegans. 5th East Asia C. elegans Meeting. Chientan Youth Activity Center, Taipei, Taiwan (June 27-30, 2012).
  5. Nishijima, S. and I. Maruyama: A new conditioning paradigm for appetitive olfactory learning in C. elegans. 5th East Asia C. elegans Meeting. Chientan Youth Activity Center, Taipei, Taiwan (June 27-30, 2012).
  6. Sassa, T. and I. Maruyama: Neuropeptide signaling plays a vital role in high alkaline-pH avoidance in C. elegans. Neuroscience 2012 (35th Annual Meeting of the Japan Neuroscience Society). Nagoya Congress Center, Aichi, Japan (September 18-21, 2012).
  7. Murayama, T., et al.: Alkaline pH sensation mediated by a transmembrane guanylyl cyclase GCY-14 in C. elegans. Neuroscience 2012 (35th Annual Meeting of the Japan Neuroscience Society). Nagoya Congress Center, Aichi, Japan (September 18-21, 2012).
  8. Itoh, B., et al.: Aversive olfactory learning and associative long-term memory in C. elegans. Neuroscience 2012 (35th Annual Meeting of the Japan Neuroscience Society). Nagoya Congress Center, Aichi, Japan (September 18-21, 2012).
  9. Nishijima, S. and I. Maruyama: New paradigm of appetitive olfactory conditioning by using alkaline pH and nonanol in the nematode Caenorhabditis elegans. Neuroscience 2012 (35th Annual Meeting of the Japan Neuroscience Society). Nagoya Congress Center, Aichi, Japan (September 18-21, 2012).
  10. Miyagi, H. and I. Maruyama: Molecular mechanism underlying activation of the EGF receptor: preformed, inactive dimer and positive cooperativity. 50th Annual Meeting of Biophysical Society of Japan. Higashiyama Campus, Nagoya University, Aichi, Japan (September 22-24, 2012).
  11. Murayama, T., et al.: Alkaline pH sensation mediated by a transmembrane guanylyl cyclase GCY-14 in C. Neuroscience 2012 (Society for Neuroscience). New Orleans Convention Center, Los Angeles, USA (October 13-17, 2012).
  12. Mise, T., et al: Crystallization of the periplasmic domain of the E. coli aspartate receptor Tar bound with a repellent. Annual Meeting of the Crystallographic Society of Japan, Katahira Campus, Tohoku University, Sendai, Miyagi, Japan (October 25-26, 2012).
  13. Murayama, T., et al.: Alkaline pH sensation mediated by GCY-14, a transmembrane guanylyl cyclase. 35th Annual Meeting of the Molecular Biology Society of Japan. Fukuoka Convention Center and Marinemesse, Fukuoka, Japan (December 11-14, 2012).
  14. Itoh, B., et al.: Aversive olfactory learning and associative long-term memory in C. elegans. 35th Annual Meeting of the Molecular Biology Society of Japan. Fukuoka Convention Center and Marinemesse, Fukuoka, Japan (December 11-14, 2012).
  15. Budiman, C., et al.: In situ visualization of mouse skeletal muscle ryanodine receptor by cryo-electron tomography. 57th Annual Meeting of Biophysical Society. Pennsylvania Convention Center, Philadelphia, Pennsylvania, USA (February 2-6, 2013).
  16. Mise, T.  Transmembrane signaling mediated by the aspartate receptor Tar, OIST, Okinawa, Japan (February 15, 2013).



5. Intellectual Property Rights and Other Specific Achievements

Nothing to report

6. Meetings and Events

6.1 Workshop

6.1.1. Two-photon Fluorescence Confocal microscopy: from beginners to experts
Organizer: Ichiro Maruyama (Information Processing Biology Unit, OIST)
Instructor: Fumiyoshi Ishidate
Dates: May 15-17, 2012
Place: Confocal rooms and Seminor rooms at OIST Lab.1

6.1.2. Single-molecule imaging in life science
Organizer: Ichiro Maruyama (Information Processing Biology Unit, OIST)
Instructor: Yasushi Sako / Yoshiro Oikawa and Yoshifumi Hasegawa from Nikon
Dates: June 5-7, 2012
Place: Confocal rooms and Seminor rooms at OIST Lab.1

6.1.3. Fast Frequency-domain FLIM for Live Cell Bioimaging
Organizer: Ichiro Maruyama (Information Processing Biology Unit, OIST)
Instructor: Michiel Kregel from Lambert Instruments BV, The Netherlands
Dates: October 23-24, 2012
Place: Confocal rooms and Seminor rooms at OIST Lab.1

6.1.4. First step for fluorescence correlation spectroscopy and fluorescence cross correlation spectroscopy of living cell
Organizer: Ichiro Maruyama (Information Processing Biology Unit, OIST)
Instructor: Masataka Kinjo / Shintaro Mikkuni / Fumiyoshi Ishidate
Dates: November 13-15, 2012
Place: Confocal rooms and Seminor rooms at OIST Lab.1
